| 7W Series Power Supply | |
| Input : | 100-240VAC, 50-60Hz |
| Output : | 3.0-24.0VDC |
| Output Power (max.) : |
7.5W |
| Safety Approval : | UL/cUL/FCC/CE/CB/GS/BS/SAA/C-Tick/PSE/K-Mark/CEC |
| Efficiency Level | CEC Level IV/V;Erp Stage I / II ; MEPS |
| Product Name | 7W Series Power Supply |
| Model Number | BI07-XXXYYY-WZ |
| Input Voltage(VAC) | 100-240 |
| Input AC Plug | US/EU/UK/SAA/PSE/korea/CCC |
| Frequency Range(Hz) | 50/60 |
| Output Power(W) | 7.5W (max) |
| Output Voltage Range(VDC) | 3.0-24.0 |
| Output Current(A) | 0.05-1.41 |
| Over Current Protection | Yes |
| Over-load Protection | Yes |
| Short Circuit Protection | Yes |
| Ripple/Noise(mV) | 10 times of rated output voltage (max) |
| Operating Temperature (℃) | 0 to 40 |
| Storage Temperature(℃) | -20 to +60 |
| Environmental Protection Standards | RoHS, REACH, WEEE,HR4040 |
| M.T.B.F(hrs) | 60,000 |
| EMC Standards | FCC PART 15 CLASS B，EN55022/EN61000-3-2/3 |
| OEM Service | Yes |
